Modular tripod PCX-020 Rescue Tripod with 20m Winch

Produkta kods: FPT
  • The PCX-020 Rescue Tripod is a mobile anchoring and lifting system designed for marine and offshore professionals requiring safe access to confined spaces such as tanks, wells, and hatches. Its robust construction and integrated rescue winch make it ideal for vertical entry and emergency retrieval operations in challenging maritime environments.

Key Features:

  • Adjustable Telescopic Legs:
    Constructed from anodized aluminum, the three legs are adjustable to accommodate various working heights and diameters.
  • Quick Assembly:
    The tripod base can be assembled and disassembled swiftly without the need for tools, facilitating rapid deployment during emergencies.
  • Integrated Rescue Winch:
    Equipped with a manual winch featuring a 5 mm galvanized steel cable, allowing for a maximum lifting distance of 20 meters.
  • High Load Capacity:
    The anchoring points have been successfully tested with a load of 150 kg, ensuring reliable performance during rescue operations.
  • Manual Locking System:
    Provides stability and prevents unintended movements during use.
  • Portability:
    With a total weight of 33 kg, the device is easily transportable across various environments.

Technical Specifications:

  • Working Height: 135 cm – 240 cm
  • Usage Diameter: 114 cm – 214 cm
  • Cable Diameter: 5 mm
  • Maximum Lifting Distance: 20 meters
  • Maximum Load Capacity: 150 kg
  • Weight: 33 kg
  • User Capacity: Single user
  • Useful Life: 10 years from manufacturing date; 5 years from first use.
  • CE Certified
  • EN 795 B
  • EN 1496 A
Izmērs:
  • One size
